Instruction Manual
922173-00 Rev A 9
Description Minimum Requirements Test Equipment Examples
Function Generator 50 Hz sine wave output
3 Vrms into 50 Ω
Agilent Technologies 33120A or
Stanford Research Model DS340
Calibration Fixture, 100 Turn
Loop
100 Turn loop in series with 0.5Ω ±
0.1% resistor with sense terminals Teledyne LeCroy CP030-CF02
Calibration Fixture ProBus Extension Cable Teledyne LeCroy PROBUS-CF01
Banana Plug Adapter Female BNC to Dual Banana Plug Pomona 1269
Patch Cables (4 required) Male Banana to Male Banana, 12" Pomona B-12-0 (black)
Pomona B-12-2 (red)
BNC Adapter BNC Male to Dual Banana Jack Pomona 1296
Preliminary Procedure
1. Connect the CP030 to the channel 1 input of the oscilloscope and completely close the probe
slider.
2. Turn the oscilloscope on and allow at least 30 minutes warmup time for the CP030 and test
equipment before performing the Verification Procedure.
3. Turn on the other test equipment and allow these to warm up for the time recommended by
the manufacturer.
4. While the instruments are reaching operating temperature, make a photocopy of the
Performance Verification Test Record (located in Appendix A), and fill in the necessary data.
Functional Check
The functional check will verify the basic operation of the probe functions.
It is recommended that the Functional Check be performed prior to the Performance Verification
Procedure.
1. Select Channel 1 and verify that the probe bandwidth is set to Full.
2. Verify that the CP030 is sensed and the CP030 tab appears in the channel menu.
3. Degauss the probe by pressing the DEGAUSS button and selecting OK (located on the CP030
dialog).
4. Verify that "Performing Degauss on CP030...." is displayed at the bottom of the screen and no
error message remains displayed.
