Operator’s Manual
922251-00 Rev A 23
Table 2 List of Required Equipment
Description Minimum Requirements Example Test Equipment
Digital Oscilloscope ProBus interface Teledyne LeCroy WavePro960
Teledyne LeCroy LT344
Digital Multimeter (DMM)
with test probe leads 4.5 digit
DC: 0.1% Accuracy
AC: 0.1% Accuracy Agilent Technologies 34401A
Fluke 8842A-09
Function Generator Sine Wave output amplitude
adjustable to 14.14 Vp-p (5
Vrms) into 1 MΩ at 70 Hz Agilent Technologies 33120A
Stanford Research Model DS340
BNC Coaxial Cable (2 ea.)
Male to Male, 50 Ω, 36" Cable
Pomona 2249-C-36
Pomona 5697-36
BNC Tee Connector Male to Dual Female Pomona 3285
Calibration Fixture ProBus Extender Cable Teledyne LeCroy PROBUS-CF01
Terminator, Precision, BNC 50 Ω ± 0.05% Teledyne LeCroy TERM-CF01
Banana Plug Adapter (2 ea.) Female BNC to Dual Banana
Plug Pomona 1269
BNC to Mini-grabber BNC Male to Mini-grabber
Cable, 36" Pomona 5187-C-36
Preliminary Procedure
1. Connect the HFP1000 probe to the female end of the ProBus Extension Cable. Connect
themale end of the ProBus Extension Cable to channel 1 of the oscilloscope.
2. Turn the oscilloscope on and allow at least 30 minutes warm-up time for theHFP1000 and
testequipment before performing the Verification Procedure.
3. Turn on the other test equipment and allow these to warm up for the timerecommended by
the manufacturer.
4. While the instruments are reaching operating temperature, make a photocopy ofthe
PerformanceVerification Test Record (located in Appendix A), and fill in the necessary data.
5. Select the channel to which the probe is connected. Set the oscilloscope scalefactor to
20mV/div.
