ASUS P4V533-MX motherboard user guide 2-13
2.4.3 Onboard Devices Configuration
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Serial Port1 Address [3F8/IRQ4]
Parallel Port Address
[Disabled]
Onboard Game Port [Disabled]
Onboard MIDI Port [Disabled]
Configure Win697 Super IO Chipset
Configure South Bridge Chipset
OnBoard LAN [Enabled]
OnBoard LAN Boot ROM [Enabled]
OnBoard AC’97 Audio [Disabled]
OnBoard MC’97 Modem [Disabled]
Configure Win697 Super IO Chipset
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address. Configuration options:
[Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Parallel Port Address [378]
Allows you to select the Parallel Port base addresses. Configuration options:
[Disabled] [378] [278] [3BC]
Parallel Port Mode [Normal]
This item appears only when the Parallel Port Address is not disabled. When set,
this item allows you to select the Parallel Port mode.
Configuration options: [Bi-directional] [EPP] [ECP]
ECP Mode DMA Channel [DMA3]
Allows selection of the Parallel Port ECP DMA channel. This item appears only
when the Parallel Port Mode is set to ECP. Configuration options: [DMA0]
[DMA1] [DMA3]
EPP Version [1.9]
Allows selection of the EPP version. This item appears only when the Parallel
Port Mode is set to EPP. Configuration options: [DMA0] [DMA1] [DMA3]
Parallel Port IRQ [IRQ7]
Allows you to select the Parallel Port IRQ. Configuration options: [IRQ5] [IRQ7]
