2
Thank you for purchasing a Superwinch product. We hope and expect that
you will be pleased with the performance and reliability of this unit. If you
are not, for any reason, please contact our Customer Service Department:
(860) 928-7787 USA; +44 (0) 1822 614101 England.
When requesting information or ordering replacement parts; always give the
following information:
1. Winch Part Number (1201, 1208, 1213, and 1215)
2. Part Number (found in Replacement Parts List section)
3. Part Description
It is extremely important that you read and understand this Owner’s Manual
prior to installing and using your winch. Pay particular attention to “General
Safety Information” and be sure that anyone else who might use your winch
also studies this section.
Pay particular attention to the caution notes preceded
with this symbol. The notes contain advice for your
protection.
Description Quantity
Winch assembly with wire rope and hook installed 1
Switch and harness assembly with two 5' long 8-gauge wires 1
and Handsaver 1
Circuit breaker assembly with hardware 1
Poly bag containing: 2 bolts, 2 lock washers, 2 nuts, 1
4 flat washers and 5 cable ties
I N T R O D U C T I O N
UNPACKING: This carton contains the following items. Please unpack care-
fully. Read instructions before beginning.
P E R F O R M A N C E
Motor
Volt Load Speed Current
DC lbs kg Ft/min m/min Amps
12 0 0 27 8.2 30
3,000 1360 5 1.5 220
24 0 0 25 7.6 15
3,000 1360 9 2.7 110
Working Load . . . 3,000 lbs. (1,360 kg)
Stall Load . . . . . . . 3,500 lbs. (1,588 kg)
Wire Rope . . . . . . . . . 7/32” x 40 ft.
Voltage . . . . . . . . 12 or 24 Volt DC
Motor . . . . . . . . . . . . . . . . . .1.3 hp
Gear Ratio . . . . . . . . . . . . . . . 148:1
Weight . . . . . . . . . . . 24 lbs. (11 kg)
S P E C I F I C A T I O N S
Slope* 10% (6º) 20% (11º) 30% (17º) 100% (45º)
Lbs.**
kg**
12,500
5670
8,500
3856
6,525
2960
3,210
1456
Ratings assume a 10% coefficient of friction.
* A 10% slope is a rise of one foot in ten feet. Slope in approximate degrees is also shown above.
** All loads shown are for single-line operation (see Figure 1). Double-line operation with optional
pulley block (P/N 2227) approximately doubles capacity of winch (see Figure 1).
ROLLING LOAD CAPACITY**
