13
1 Handsaver 90-32300 1
2 7/32" x 40' Wire Rope and Hook Assembly 1513 1
3 Base Plate, Model X2 90-41019 1
Base Plate, Model X2F 90-32067 1
4 Pair 3/8" Bolts & Nuts, 4 Flat and 2 Lock Washers 90-22892 1
5 1/4 - 20 Flange Nut 90-23149-02 1
6 Wire Rope Guide 1507 1
8 1/4 - 20 x 3/4" Hex Soc. Flat Head Screw 90-23056-04 1
9 5/16 - 18 x 3/4" Hex Soc. Flat Head Screw 90-23056-02 2
11 Assembly of Three Circuit Breakers on Bracket 90-22883 1
16 Free Spool Shaft Ass'y 90-12534 1
17 Outboard Housing 90-32058 1
18 Flange Bushing 90-23167-01 1
19 Washer 90-23120-11 1
20 Drum Assembly, Model X2F Only 90-32054 1
21 Wire Rope Tension Plate Set, Model X2 90-12450 1
Wire Rope Tension Plate Set, Model X2F 90-12536 1
22 Rotating Drive Shaft Assembly 90-32057 1
23 Carrier Bearing 90-23140 2
24 Planetary Gear Assembly 90-23138 1
25 Nylon Step Washer 90-12418 1
26 8 Tooth Sun Gear 90-23141 1
27 Flat Thrust Washer 90-23120-08 1
28 Perimeter Bearing 90-23137 1
29 1.3 H.P. 12 Volt Motor with Gearbox and 90-12452 1
Needle Bearing. Primed
29A Main Gearbox with Needle Bearing 90-12454 1
30 Replacement Switch Assembly with (2) 3 Foot Leads 1519 1
Includes two Butt Splices for connecting to old
harness
31 Shim Washer 90-23120-05 1
32 Bushing 90-12174 1
33 Wire Rope Retainer 90-12419 1
35 Drum Assembly 90-32034 1
Reference
Number
Description Part Number Qty
R E P L A C E M E N T
P A R T S L I S T
R E P L A C E M E N T
P A R T S L I S T
