NVR-02 Series User Manual 9
LED Definition
HDD
Green Solid green when the hard disk is mounted and
being accessed.
Red Solid red for disk fail.
Amber Solid amber when recording is in process.
Blinking when recycling.
Network
Amber Solid amber for activity on a 1G bps network.
Green Solid green for activity on a 10/100 Mbps network.
Status
Amber Blinking during firmware upgrade.
Green Shows solid green for normal operation.
Blinking green when firmware upgrade is done.
Red Flashes red for failed firmware upgrade.
Power
Green Normal operation.
Red System off (power adapter remains plugged in).
Amber Blinking amber indicating device is initializing.
Alarm
Red Blinking when an alarm occurs.
None When alarm is reset.
Camera
LED
Green
Solid green, live connected with no event or
recording activity.
Amber Blinking amber, manual or event recording is
being performed.
Amber Solid amber, schedule or continuous recording is
being performed.
Red Recording is set but no video from camera.
