King Electric Model HT - Manual (Page 3)

backside
2½"
13¼"
left side
5"
right side
½" electrical
knockout
" hole size 12 "
3 "
20 "
3 5/16"
(18¼" without grille)
3 "
without
grille
12 "
18 "
interior
18 " without grille
water feed
wiring
junction box
mounting
slots
mounting
slots
LEGEND
SC - switch common
SC-R - switch common 2/3 & 3/4
SH - switch high speed
SL - switch low speed
MH - motor high lead
ML - motor low lead
M - motor common
Q1 - aqua switch
Q2 - aqua switch
L1Q - power lead with aquastat
L1XQ - power lead without
aquastat
N - neutral lead
HT wiring:ai : 1/10
Neutral
White
White
Fan Switch
Hi / Low
Black
Red
White
Black
High
Speed
Red
Low
Speed
Aquastat
120 Volt
with
Aquastat
120 Volt
without
Aquastat
Black
Power
Black
Option
N
SC
SC-R
L1Q SH
MH ML Q1 Q2
SL L1 XQ
M
Blue
Optional
Motor Speed Resistor
SAVE THESE INSTRUCTIONS
INSTALLATION INSTRUCTIONS
KING ELECTRICAL MFG. COMPANY · 9131 10TH AVENUE SOUTH · SEATTLE, WA 98108 · PH: 206.762.0400 · FAX: 206.763.7738 · www.king-electric.com
HT.indd : 1/10
Specifications:
HT Model Number Legend
HT 8 12 5/7 AS-FS GW
H
8
12
5
/
7
H Series Hot Water
Voltage 120
5000 BTU heat output @ 140 Degree water input
7000 BTU heat output @ 160 Degree water input
Inlet water temperature range: 100 to 200 Degree F
Air Delivery: 30 to 50 CFM
CFM High Speed: 50
Motor Amps .48 @ 120 Volt
CFM Low Speed: 30 Motor Amps .40 @ 120 Volt
Power Supply: 110 to 125 Volt AC 50/60 cycle
Electrical Circuit Sizing
Maximum 15 Amps
circuit breaker or fusing
One year warranty from date of installation
Number of copper tubes in coil
AS-FS
GW Grille White or Black color
Aqua Stat / Fan Switch
T
T Toe Space
