GENERAL INFORMATION
WARNING
HT SERIES
Hydronic Toe Space Heaters
Under Cabinet Heaters
SAVE THESE INSTRUCTIONS
KING ELECTRICAL MFG. COMPANY · 9131 10TH AVENUE SOUTH · SEATTLE, WA 98108 · PH: 206.762.0400 · FAX: 206.763.7738 · www.king-electric.com
READ ALL WIRE SIZING, VOLTAGE REQUIREMENTS AND SAFETY
DATA TO AVOID PROPERTY DAMAGE AND PERSONAL INJURY
DANGER
ELECTRIC SHOCK OR FIRE HAZARD
READ CAREFULLY - These instructions were written to help prevent diffi culties that might arise during installation of this
heater. Studying the instructions fi rst may save you considerable time and money later. Observing the following procedures
will cut the installation time to a minimum. King encourages you to save these instructions for future reference.
Thank you for buying this King HT series heater. It should provide years of trouble-free service and comfort to your home.
Please inspect the package to ensure the heater coil and fan, with grill and screws are included.
Here are a few tips in getting the heater installed correctly!
1. LOCATION: This heater is intended to be installed under a kitchen or bathroom cabinet in the toe space area although other locations are
possible.
2. BATHROOMS: Under the vanity is an ideal location for the HT Series. Placement should be off to one side or the other from where people
will be standing at the sink as the heat discharged could cause discomfort or minor burns to skin if exposed for long periods of time.
3. KITCHENS: This heater is conveniently sized for placement under the kitchen sink cabinet. Placement should be off to one side or the other
from where people will be standing at the sink, as the heat discharged could cause discomfort or minor burns to skin if exposed for long periods
of time.
4. LIVING ROOMS: In the step or a deep wall is a good location for the HT Series. This style of heater has a higher sound rating than the
standard H Series at high speed.
5. MOUNTING:
New construction: Place this heater on the fl oor where the cabinet will be over the top. Add underlayment under heater if that will be used on
the fl oor in front of the cabinet. Take cover off and mount to the fl oor through the holes provided on the bottom side. Use only the screws holes
in the front outlet by the grille so that you can remove them if you need to adjust the wall can forward or backward to match up with the toe
board for the grille.
Remodel or cabinets in place: Cut the toe kick area the proper width to install in toe board.
HT.indd : 1/10
tested to:
1995 standards
