9.9 Top Hook Parts
Figure
No.
Part Name
Parts
Per
Hoist
200S
1
Top Hook Complete Assembly
1
ER2KS1011
2
Top Suspension Plate A Assembly
1
ER2KS5011
3
Top Suspension Plate B Assembly
1
ER2KS5012
4
Suspender Shaft B
4
E6S013150
5
Top/Bottom Hook Assembly
1
ER2KS2121
7
Thrust Bearing
1
E6S038150
8
Bearing Cover
1
E6S023200
9
Hook Nut
1
E6S024200
10
Bottom Yoke
1
E6S030200
11
Safety Latch Assembly
1
C2BA3001071
12
Stopper Screw A
1
J1TB01110016
13
Stopper Screw B
1
J1TB01110010
14
Bottom Stay Bolt
8
E6S038150
15
Bottom Idle Sheave Assembly
3
ER2HS5052
16
Thrust Needle Bearing
6
ER1HS9182
17
Shaft Stopper A
2
ER1IS9056
18
Top Shaft B
3
E6S067150
19
Shaft Stopper B
3
ER1JS9060
20
Guide Roller
8
E6S062075
21
Bottom Collar
8
E6S065150
22
Nut
16
9093445
23
Spring Washer
16
9012717
24
Socket Bolt
10
9091271
25
Spring Washer
10
9012711
26
Connection Yoke Assembly
2
ER2IS5005
