9.8 Top Suspension Plate Parts
Figure
No.
Part Name
Parts
Per
Hoist
080S 100L 100S
1 Top Suspension Plate Assembly 1 ER2HS1003 ER2IS1003
2 Top Suspension Plate A Assembly 1 ER2HS5003 ER2IS5003
5 Top Suspension Plate B Assembly 1 ER2HS5004 ER2IS5004
8 Top Stay Bolt 3 (4) E6S007075
9 Suspension Shaft 2 (4) E6S008075
10 Top Idle Sheave Assembly 1 ER2HS5051
11 Thrust Needle Bearing 2 ER1HS9182
12 Top Shaft 1 E6S053075
13 Shaft Stopper A 2 (3) ER1HS9056
14 Guide Roller 4 E6S062075
15 Nut 6 (8) 9093445
16 Spring Washer 6 (8) 9012717
17 Socket Bolt 4 (6) 9091271
18 Spring Washer 4 (6) 9012711
19
Stopper Shaft 1 E6SE075S9010
Stopper Shaft (300) 1 E7SE075S9019
20 Split Pin 2 9009448
21 Chain Holder 1 ER1IL9017
22 Chain Pin 1 E6S041075
23 Snap Ring 1 9047221
24 Connection Yoke Assembly 1 ER2HS5005
ER2IS5005
(2 Required)
*Quantities in “( )” are for 10 ton hoists.
