Page 49
9.9 Top Hook Parts
Figure
No.
Part Name
Parts
Per
Hoist
150S
1
Top Hook Complete Assembly
1
ER2JS1011
2
Top Suspension Plate A Assembly
1
ER2JS5011
3
Top Suspension Plate B Assembly
1
ER2JS5012
4
Suspender Shaft B
4
E6S013150
5
Top/Bottom Hook Assembly
1
ER2JS2121
7
Thrust Bearing
1
ES022150
8
Bearing Cover
1
E6S023150
9
Hook Nut
1
E6S024150
10
Bottom Yoke
1
E6S030150
11
Safety Latch Assembly
1
M2071200
12
Stopper Screw A
1
J1TB01110016
13
Stopper Screw B
1
J1TB01110010
14
Bottom Stay Bolt
7
E6S038150
15
Bottom Idle Sheave Assembly
2
ER2HS5052
16
Thrust Needle Bearing
4
ER1HS9182
17
Shaft Stopper A
2
ER1IS9056
18
Top Shaft B
2
E6S057150
19
Shaft Stopper B
2
ER1JS9060
20
Guide Roller
6
E6S062075
21
Bottom Collar
6
E6S065150
22
Nut
14
9093445
23
Spring Washer
14
9012717
24
Socket Bolt
8
9091271
25
Spring Washer
8
9012711
26
Connection Yoke Assembly
2
ER2IS5005
