9.9 Top Hook Parts
Figure
No.
Part Name
Parts
Per
Hoist
100L
100S
1
Top Hook Complete Assembly
1
ER2IS1011
2
Top Suspension Plate A Assembly
1
ER2IS5011
3
Top Suspension Plate B Assembly
1
ER2IS5012
4
Suspender Shaft B
4
E6S013100
5
Top/Bottom Hook Assembly
1
ER2IS2121
7
Thrust Bearing
1
ES022100
8
Bearing Cover
1
E6S023100
9
Hook Nut
1
ES024100
10
Bottom Yoke
1
E6S030100
11
Safety Latch Assembly
1
C2BA1501071
12
Stopper Screw A
1
J1TB01110016
13
Stopper Screw B
1
J1TB01110008
14
Bottom Stay Bolt
4
E6S038075
15
Bottom Idle Sheave Assembly
1
ER2HS5052
16
Thrust Needle Bearing
2
ER1HS9182
17
Shaft Stopper A
3
ER1IS9056
18
Top Shaft B
1
E6S057100
20
Guide Roller
4
E6S062075
21
Bottom Collar
4
E6S065075
22
Nut
8
9093445
23
Spring Washer
8
9012717
24
Socket Bolt
6
9091271
25
Spring Washer
6
9012711
26
Connection Yoke Assembly
2
ER2IS5005
27
Connection Yoke Assembly
1
ER2IL5155
28
Yoke Bolt
1
ER1ES9032
29
Slotted Nut
1
ES088020L
30
Split Pin
1
9009436
31
Chain Pin
1
ES041050
32
Slotted Nut
1
M2049030
33
Split Pin
1
9009424
34
Chain Holder
1
ER1IL9171
35
Chain Pin
1
E6S041075
36
Snap Ring
1
9047221
37
Balance Weight Assembly
1
7021002
