Page 25
9.1 Housing and Motor Parts
Figure
No.
Part Name
Parts Per
Hoist
080S
100L
100S
150S
200S
1
Fan Cover
1 (2)
ER2ES9107
2
Fan
1 (2)
ER2ES9108
3
Snap Ring
1 (2)
9047122
4
Brake Cover
1 (2)
ER2ES9115
5
Packing B
1 (2)
ER2ES9119
6
Set Pin S
2 (4)
ES120003
7
Socket Bolt
4 (8)
9091255
8
Electromagnetic Brake Assembly
1 (2)
MBABB35NA
9
Key B
1 (2)
ER2ES9360
10
Snap Ring
1 (2)
9047130
11
Socket Bolt
3 (6)
9091278
12
Spring Lock Washer
3 (6)
9012712
13
V Ring
1 (2)
ER2ES9210
14
Motor Shaft With Rotor
1 (2)
ER2FS5502
15
Ball Bearing
1 (2)
9000907
16
Ball Bearing
1 (2)
9000906
17
Motor Frame With Stator
1 (2)
ER2BKV25S5A1
18
Packing M
1 (2)
ER2FS9118
19
Set Pin S
2 (4)
ER2ES9138
20
Socket Bolt
4 (8)
90912116
21
Body B
F
1 (2)
ER2FS6101
Body C
M
ER2FS6099
22
Oil Plug
1 (2)
E3S111003
23
Plug Packing
1 (2)
E3S112003
24
Snap Ring
1 (2)
9047280
25
Gear Case
F
1 (2)
ER2FS6103
M
ER2FS6102
26
Oil Plug
1 (2)
E3S111003
27
Plug Packing
1 (2)
E3S112003
28
Spring Pin
1 (2)
E3S129005S
29
Packing G
F
1 (2)
ER2FS9116
M
2 (4)
30
Set Pin S
F
2 (4)
ES120010S
M
4 (8)
31
Socket Bolt
F
5 (10)
9091286
M
90912155
32
Toothed Lock Washer
5 (10)
9679711
33
Oil Fill Plug
1 (2)
ER1BS9135
34
Eyebolt Packing
1 (2)
ES127005S
35
Name Plate Load Side
1 (2)
ER1BS9960
36
Oil Full Tag
1 (2)
ER1BS9953
37
Warning Sticker E (Disconnect Power)
1 (2)
ER2CS9936
38
Name Plate OF (Correct Oil Required)
F
1 (2)
ER2CS9845
Name Plate OM (Correct Oil Required)
M
ER2CS9846
40
Name Plate AD (Speed Letter)
1 (2)
ER1BS9868
ER1BL9868
ER1BS9868
41
Connection Shaft Assembly
1 (2)
ER2FS6121
42
Top Pin Plug Assembly
1 (2)
ER2FS6128
43
O Ring
2 (4)
9013317
44
Fixing Shaft Assembly
1 (2)
ER2FS6122
45
Fixing Shaft Plug Assembly
1 (2)
ER2FS6131
46
O Ring
2 (4)
9013307
47
Connection Shaft Plate A
1 (2)
ER1ES9123
48
Socket Bolt With Spring Washer
2 (4)
J1BG10601616
49
Plate A
1 (2)
ER1BS9123
50
Machine Screw With Spring Washer
2 (4)
M6F554010
51
Check Voltage Label
S,2V
1
ECP99NVVB
S,4V
ECP99NVVA
D,2V
ECP99NVWB
D,4V
ECP99NVWA
52
Name Plate AA (With Mechanical Brake)
M
1
ER1BS9893
53
Warning Sticker HW (Hot Surface)
D
1
ER2CI9806
*Quantities in “( )” are for dual-body hoists.
