DipSwitch 5 Dipswitch 6
Output under
test goes to
this level
off off 100%
on off 50%
off on 25%
on on
Disables ALL
ʻTestsʼ
7. ! DipSwitch 7: European (0-511) or USA (1-512) DMX-512 Addresses
On version 3.0+ Lg-DMX/DC, this switch allows you to select whether the DMX-512 addresses set on
the three rotary switches are entered in the European (0-511) or American (1-512) ranges of numbers. The
American DMX-512 channel ‘1’ is the same as the European DMX-512 channel ‘0’. This feature was not
available on previous versions of the Lg-DMX/DC.
a) If off, then DMX-512 addressing is from 0-511
b) If on, then DMX-512 addressing is from 1-512
Most GilderGear uses the European-style (0-511) addressing.
8. ! DipSwitch 8: Disable on loss of DMX-512
On version 3.0+ Lg-DMX/DC, The Lg-DMX/DC can be set turn off all the outputs when the DMX-512
input goes away. On previous versions of the Lg-DMX/DC, this feature was on Dipswitch #2-10
a)
If off, then all outputs will be forced ‘off’ approximately ten seconds after the DMX-512 is lost.
b)
If on, then the outputs will stay at the last level set by the DMX-512, even after the DMX-512 has
gone away.
