Install Software… FIRST
A. Power Mac G4 (MDD) Users ONLY—Verify and Update
Power Mac Firmware (if Necessary)
If your computer is a Xserve G4 model, skip to section C on page 2.
Otherwise, before installing the Duet, you must ensure your system’s
firmware has been updated to version 4.4.8f2 or higher (e.g. “4.5.7f1”).
Please note, your system may need to connect to the Internet to perform
some of the steps.
1. OS X users: Open System Profiler (located within the Utilities
folder found in the Applications folder). Find the Boot ROM
information listed in the Hardware Overview pane
(Figure 1).
If it reads “ 4.4.8f2” or higher (e.g. “4.5.7f1”), skip the rest of
the steps in this section and proceed to section C on page 2.
Otherwise, go to step 2.
OS 9 users: Select and open Apple System Profiler from the Apple
Menu. Click the triangle next to Production Information, and
find the Boot ROM version information
(Figure 2). If it reads
“ $0004.48f2” or higher (e.g. “4.5.7f1”), skip the rest of the steps
in this section and proceed to section C on page 2. Otherwise, go
to step 2.
2. OS X users: Log on to the Internet and type the following in your
browser window’s address bar:
http://docs.info.apple.com/article.html?artnum=120186
OS 9 users: Log on to the Internet and type the following in your
browser window’s address bar:
http://docs.info.apple.com/article.html?artnum=120171
3. Click on the appropriate link to download the firmware.
4. Double-click the G4FWUpdate.dmg.bin or
G4FWUpdate4.4.8.smi file icon to mount the G4 Firmware
Update disk image. Double-click the disk image icon, and then
double-click the enclosed file to launch the updater application.
Print the read me file, and then following the directions on the
pages you printed, update the firmware on your system.
B. ALL USERS—Install or Upgrade to Mac OS X Version
10.3.5 or Later, If Necessary
For Mac OS X compatibility, the Encore/MDX G4 Duet card
requires Mac OS X Version 10.3.5 or later. If you are upgrading to
Mac OS X as part of this installation, or need to update Mac OS X to
the latest version, do so now; complete the Mac OS upgrade, and then
restart your computer.
Figure 2
Figure 1
firmware version
Mac OS X Alert: Due to technical issues that arise from
the operation of the latest G4 processors (used on this
Encore/MDX G4 Duet card) in an older system, you must use
Mac OS X Version 10.3.5 or later to ensure compatibility; earlier
versions of Mac OS X lack the proper processor support.
firmware
version
