6

Quick Start Guide for Tempo-X eSATA 4+4

Drive Formatting—Individual Drives (continued)

7. When the Partition Disk window appears, click the Partition button

(Figure 7). If necessary, repeat steps 3–6 to partition any other drives con-
nected to the Tempo-X card. When partitioning and formatting are com-
plete, close the Disk Utility application; you can now use your drive(s).

Drive Formatting—RAID Arrays

This section describes the process of formatting (initializing) multiple hard
drives connected to the Tempo-X eSATA 4+4 to create a RAID 0 (striped) array
using Disk Utility under Mac OS X Version 10.3; the process under Versions
10.4 and 10.2 are similar. If you choose to do so, you may format your drives
using SoftRAID 3.1 or later; refer to that product’s documentation for instruc-
tions.

1. Turn on your computer. During startup, your computer may display a

message(s) referring to unreadable volumes; click Initialize… to launch
Disk Utility

(Figure 8).

2. If it is not already open, launch Disk Utility (Figure 9). Note that all

attached drives appear in the information window, regardless of being for-
matted or not.

Figure 7

Figure 8

Figure 9

Support Note:

See page 8 for port identification and information on

Tempo-X eSATA 4+4’s status LEDs.
