Using the Interface Cables
Positioning the Sensor
•
Select the proper size band for the patient.
1. Strap the sensor bands around the patient’s abdomen or chest, over any clothing.
2. Attach the first wire to the snap that is on the same side of the band as the Velcro® patch.
3. While holding this end to the left of the patient’s centerline, wrap the band around the patient’s
chest or abdomen. For smaller patients move the starting point further to the left.
4. Pull the other end over the first end and secure to the band on the right side of the centerline. The
band should be snug but not too tight.
5. Attach the second wire to the exposed snap. Secure both wires about 3” away from the connection.
•
Check that clear, strong signals are being transmitted before leaving the patient.
•
When removing the sensor band do not pull on the wires. Remove from the snap.
Item:
Length:
Operating conditions:
Storage temperature:
Operating and storage humidity:
•
SleepSense
sensors are for professional use only.
•
SleepSense
sensors are for sale by or on the order of a physician only.
•
SleepSense
sensors may be used only in conjunction with an approved recording system.
•
SleepSense
sensors are only intended for use on healthy skin.
•
Discontinue use if sensor shows signs of wear, damage, or exposed metal.
Thank you for purchasing a SleepSense® sensor
Cleaning the Interface Cable
•
Wipe the Interface Cable with a non-corrosive (to plastic) cleanser to clean before use.
•
Make sure the cable is thoroughly dry before reusing it.
•
Do not autoclave or soak the cable in disinfectants.
9141 / 9142
9151 / 9152
1.5 ft
8 ft
5ºC (40ºF) -- 40ºC (104ºF)
-20ºC (-4ºF) -- 60ºC (140ºF)
5% -- 95% (Non-condensing)
Indications for use
SleepSense sleep-lab sensors provide a qualitative measure of sounds, respiratory-effort, flow, body
position or limb movements, for recording on an approved data acquisition system. They are intended
for use on children and adult patients who are screened during sleep disorder studies at a sleep
laboratory or the patient’s home.
Technical Specifications:
Description
The RIP Interface Cables are intended to connect between the SleepSense Inductive Bands and
any PSG system with a built-in Inductive channel.
Warnings and Precautions
Limited Warranty
SLP warrants the Inductive Interface able to be free of defects in materials and workmanship for a period of three months from the date
purchased. The sole liability of SLP and our distributor(s) is limited to replacement or repair of the product at the option of SLP with no charge
for parts or labor if any part is proven to be defective in workmanship, performance, or materials during the warranty period. Under no
circumstances shall SLP or our distributor(s) be liable for any loss of revenues or damage, direct, consequential, or incidental, including loss
of profit, property damage, or personal injury arising from the use of, or the inability to use this product. This warranty is intended only for the
original buyer and is in lieu of all other warranties or previous agreements, expressed or implied. This warranty is rendered void if the product
is used for other than its intended purpose or is subject to abuse, misuse, tampering, neglect, or unauthorized modifications. Use of this product
constitutes acceptance of this warranty in total.
For a complete list of technical specifications please contact us or visit our website.
