AQU244 & AQU128 Series Installation Instructions
AQU244 & AQU128 Series Instructions Doc.#500-33020 Rev. A
Page 3 of 5
Specifications
AC INPUT: 3 position terminal block in High Voltage barrier. Line, Neutral, and Earth Ground
AC Input .......................................................................... ............................... 90-240vac/47-63Hz/220Watts Max
Wide range AC input does not require any selection switching. Earth ground terminal must be properly connected to earth
ground. Note: The Ground connection is connected to the enclosure back with a metal standoff. In the case of
enclosures with a removable lid, a ground wire is used to ensure the ground continuity to the lid. If lid is removed,
this ground wire must be reconnected securely.
AC Fuse Link is inside unit for catastrophic failure. This fuse is not field replaceable, unit must be returned to factory for service should this fuse
blow. A blown fuse is indicated by the AC LED off with AC power applied.
DC OUTPUT(S):
AQU244 Output Rating .................................................... .................................... 18.5-28.0vdc, 24vdc nominal, 4A
AQU128 Output Rating ……………………………………………..…………………….9.7-14.0vdc, 12vdc nominal, 8A
Note: The AQU244 has 1 Amp in reserve for battery charging while the AQU128has 2 Amps in reserve for Battery
Charging.
Typical Output Voltage AQU244/AQU128 ....................... ........................................................... 27.5vdc/13.75vdc
Typical Output Ripple & Noise AQU244/AQU128 ........... ..................................................................... 30mv/15mv
Current Overload Short Circuit Protection ....................... ................................................................................. Yes
Note: Output is short circuit protected with electronic power limiting (Not Class II) and a self-resetting circuit breaker
in series with Battery.
Service Switch Disables DC power and Battery from Output ............................................................................ Yes
(Note: The service switch has been removed on European models AQU224-E & AQU128E with CE mark)
Battery PTC Circuit Breaker AQU244/AQU128 ............... ............................................................................... 6A/9A
Over Temperature protection ........................................... .................................................................................. Yes
Ambient Operating Temperature Range ........................ ..................................................................... 0
o
C to 49
o
C
Switching Frequency ....................................................... ............................................................................ 23KHz
Battery Cutoff Voltage AQU244/AQU128 ........................ ................................................................ 9.9vdc/19.8vdc
Battery Cutoff relay contacts ........................................... .................................................................. 20A Resistive
Note: Battery Cutoff Relay is normally energized for fail-safe operation
Power Trouble trip points AQU244 .................................. ..................................................... <24.2vdc or >28.2vdc
Power Trouble trip points AQU128 .................................. ..................................................... <12.1vdc or >14.1vdc
Trouble Relay Form C Contacts ...................................... .............................................................. 2A up to 120vac
Relay is normally energized for fail-safe operation.
Battery Charging: (Keyed header plug marked –Bat+)
The battery charger is precision set to float charge 12v or 24v sealed or wet lead acid batteries. Typically two 12v
batteries are connected in series for 24v. The Amp hour capacity must be between 4Ah and 40Ah capacity.
Mechanical Characteristics:
Smart Fan comes with models mounted in an enclosure. The smart fan adjusts fan speed to keep power supply
cool.
AQU244/AQU128 weight (in enclosure) .......................... ............................................................................ 12.8 lbs
AQU244/AQU128 mounting holes center to center (4 holes) ........................................................... 3.5”H x 6.8”W
Enclosure size ................................................................. .............................................................. 14” x 14” x 4.75”
Approvals: The AQU244 and AQU128 are the only products UL listed.
Specifications are subject to Change without notice.
