Ronan X57 User Manual
Page 6
X57
C h a s s i s O p t i o n s ( S u r f a c e M o u n t )
C h a s s i s O p t i o n s ( S u r f a c e M o u n t )
S u r f a c e M o u n t f o r A c t i v e a n d Z e n e r B a r r i e r s
X57-SM-10
X57-SM-4
with Ground Bars
X57-SM-1
with Ground Bars
5.94 in.
(150.82 mm)
3.56 in.
(90.81 mm)
2
4
3
1
2
4
3
1
2
4
3
1
2
4
3
1
2
4
3
1
2
4
3
1
2
4
3
1
2
4
3
1
2
4
3
1
2
4
3
1
C
D
B
A
.91 in.
(23.11 mm)
1.71 in. (43.43 mm)
4.00 in.
(101.60 mm)
.21 in. (5.41 mm)
4 Places
I.S.
GND
V+
V–
10
9
8
7
6
5
4
3
2
1
Active
Isolated
Barrier
Module
Zener Diode
Barrier
Module
Ground Bar
Ground
Connection
Clamp
18GA, Green
In/Out
1 to 4
Channels
Used
Extended
Ground
Connection
Optional
I.S.
Gound
I.S.
Ground
In/Out
1 to 4
Channels
Used
Ground
Connection
Ground Bar
Clamp
Extended
Ground
Connection
Optional
Hazardous
Area
Safe
Area
24 Vdc
18GA, Green
5
6
7
8
4
3
2
1
V+
V–
6
8
7
5
2
4
3
1
5.80 in.
(147.32 mm)
3.57 in.
(90.68 mm)
.16 in. (93.96 mm) Dia.
4 Places
4.00 in.
(101.60 mm)
5.82 in. (147.82 mm)
2.96 in.
(75.56 mm)
2.58 in.
(65.40 mm)
.91 in.
(23.11 mm)
Active
Isolated
Barrier
Module
Zener Diode
Barrier
Module
2
4
3
1
I.S.
GND
V–
V+
Ground Bar
Ground Connection
18GA, Green
In/Out
1 to 4
Channels
Used
Extended
Ground
Connection
Optional
I.S. Ground
In/Out
1 to 4
Channels
Used
24 Vdc
18GA, Green
5
6
7
8
4
3
2
1
V+
V–
I.S. Ground
6
8
7
5
2
4
3
1
Hazardous
Area
Safe
Area
6
X 5 7 S M - 1
X 5 7 S M - 1 0
X 5 7 S M - 4 , - 1 0 , - 1 6 , a n d - 2 0 W i r i n g
X 5 7 S M - 1 W i r i n g
MODEL NO. DIMENSION A DIMENSION B DIMENSION C DIMENSION D
X57SM-4
5.68 in. (144.27 mm)
5.28 in. (134.11 mm)
5.82 in. (147.82 mm)
X57SM-10
11.05 in. (280.67 mm)
10.65 in. (270.51 mm)
5.82 in. (147.82 mm)
X57SM-16
16.42 in. (417.07 mm)
16.02 in. (406.91 mm)
5.82 in. (147.82 mm)
X57SM-20
20.00 in. (508.00 mm)
19.60 in. (497.84 mm)
5.82 in. (147.82 mm)
X57SM-4EG
5.68 in. (144.27 mm)
5.28 in. (134.11 mm)
7.42 in. (188.46 mm)
X57SM-10EG
11.05 in. (280.67 mm)
10.65 in. (270.51 mm)
7.42 in. (188.46 mm)
X57SM-16EG
16.42 in. (417.07 mm)
16.02 in. (406.91 mm)
7.42 in. (188.46 mm)
X57SM-20EG
20.00 in. (508.00 mm)
19.60 in. (497.84 mm)
7.42 in. (188.46 mm)
Extended Ground Connection (Contact Ronan for complete model numbers)
Maximum Number of Modules (Position)
