AdaptaFlow Node Adapter - Operation
Input Word 1 Input Word 1 Input Word 1 Input Word 1 Input Word 1
B i t B i t B i t B i t B i t Description Description Description Description Description
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15 CPU OK Channel #1
First Powerup Flag Channel #1
Closed Loop Channel #1
Setpoint Achieved Channel #1
Low Rate Limit Alarm Channel #1
High Rate Limit Alarm Channel #1
Total Flow Limit 1 Alarm Channel #1
Total Flow Limit 2 Alarm Channel #1
CPU OK Channel #2
First Powerup Flag Channel #2
Closed Loop Channel #2
Setpoint Achieved Channel #2
Low Rate Limit Alarm Channel #2
High Rate Limit Alarm Channel #2
Total Flow Limit 1 Alarm Channel #2
Total Flow Limit 2 Alarm Channel #2
Input Word 2 Input Word 2 Input Word 2 Input Word 2 Input Word 2
B i t B i t B i t B i t B i t Description Description Description Description Description
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15 CPU OK Channel #3
First Powerup Flag Channel #3
Closed Loop Channel #3
Setpoint Achieved Channel #3
Low Rate Limit Alarm Channel #3
High Rate Limit Alarm Channel #3
Total Flow Limit 1 Alarm Channel #3
Total Flow Limit 2 Alarm Channel #3
CPU OK Channel #4
First Powerup Flag Channel #4
Closed Loop Channel #4
Setpoint Achieved Channel #4
Low Rate Limit Alarm Channel #4
High Rate Limit Alarm Channel #4
Total Flow Limit 1 Alarm Channel #4
Total Flow Limit 2 Alarm Channel #4
Output Word 1 Output Word 1 Output Word 1 Output Word 1 Output Word 1
B i t B i t B i t B i t B i t Description Description Description Description Description
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15 Totalizer Reset Channel #1
Transparent Mode Channel #1
Hold Mode Channel #1
Hold Totalizer Channel #1
Trigger On Channel #1
First Power On Channel #1
Not Used
Not Used
Totalizer Reset Channel #2
Transparent Mode Channel #2
Hold Mode Channel #2
Hold Totalizer Channel #2
Trigger On Channel #2
First Power On Channel #2
Not Used
Not Used
Output Word 2 Output Word 2 Output Word 2 Output Word 2 Output Word 2
B i t B i t B i t B i t B i t Description Description Description Description Description
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15 Totalizer Reset Channel #3
Transparent Mode Channel #3
Hold Mode Channel #3
Hold Totalizer Channel #3
Trigger On Channel #3
First Power On Channel #3
Not Used
Not Used
Totalizer Reset Channel #4
Transparent Mode Channel #4
Hold Mode Channel #4
Hold Totalizer Channel #4
Trigger On Channel #4
First Power On Channel #4
Not Used
Not Used
1 2 1 2 1 2 1 2 1 2
Figure 6: Input Word 1 Figure 6: Input Word 1 Figure 6: Input Word 1 Figure 6: Input Word 1 Figure 6: Input Word 1 Figure 7: Input Word 2 Figure 7: Input Word 2 Figure 7: Input Word 2 Figure 7: Input Word 2 Figure 7: Input Word 2
Figure 8: Output Word 1 Figure 8: Output Word 1 Figure 8: Output Word 1 Figure 8: Output Word 1 Figure 8: Output Word 1 Figure 9: Output Word 2 Figure 9: Output Word 2 Figure 9: Output Word 2 Figure 9: Output Word 2 Figure 9: Output Word 2
