Turbodisk 2 - Parts Identification
71
* See corresponding column in Table "A"
1 Retainer, Bearing 70873-00 1
2 Screw, #6-32 x 3/8 Long, Hex Socket, Flat Head 78232-12C 12
3 Slinger 70876-00 1
4 Spacer, Bearing 20298-00 1
5 Bearing, Ball 70896-00 2
6 O-Ring, 1.614 I.D., Solvent Resistant 7554-77 1
7 O-Ring, 3.489 I.D., Solvent Resistant 7554-73 1
8 Decal, 20292-xx Turbodisk 73180-02 1
9 Key, Woodruff, 1/2 Dia. 8310-01 1
10 Nut, Self-Lock, 5/8-18, UNF 7729-10 1
11 Seat, Spring 20966-00 1
12 Spring, Compression 70868-00 1
13 Screw, Set, Special 70871-00 1
14 Housing, Bearing, Machined 70875-00 1
15 O-Ring, 2.239 I.D., Solvent Resistant 7554-17 1
16 Plate, Nozzle A* 1
17 Rotor, Turbine B* 1
18 Shaft, Air Motor C* 1
Item #
70879-xxx TURBODISK 2 TURBINE CARTRIDGE ASSEMBLY -
PARTS LIST (Figure 28)
Part # Description Qty
Part # Description A
TABLE "A" (Figure 28)
B
70879-206
70879-256
70879-406
70879-456 Motor, Turbodisk 2, CW Rotation
Motor, Turbodisk 2, CCW Rotation
Motor, Turbodisk 2, CW Rotation
Motor, Turbodisk 2, CCW Rotation
C
20291-06
20291-56
20291-10
20291-60 20292-31
20292-32
20292-31
20292-32 70897-01
70897-02
70897-01
70897-02
LN-9240-02.1
