Ransburg Turbodisk 2 Assembly 78715 User Manual
Page 19
Turbodisk 2 - Installation
15
Figure 3b: Turbodisk 2 Signal/Port Identification Table
Designation as Marked
on Bulkhead
TURBODISK 2 SIGNAL/PORT IDENTIFICATION TABLE
(Figure 3b)
Description
Tubing Color
F.O
HV
P1D
P1DL
R1H
R1L
P1S
P1R
P1T
P2D
P2DL
R2H
R2L
P2S
P2R
P2T
S1.IN
S2.IN
T.A1
T.A2
Fiber Optic Cable
High Voltage Cable
Paint #1 Dump
Paint #1 Dump Line
Regulator #1 High
Regulator #1 Low
Paint #1 Supply Line
Paint #1 Return Line
Paint #1 Trigger
Paint #2 Dump
Paint #2 Dump Line
Regulator #2 High
Regulator #2 Low
Paint #2 Supply Line
Paint #2 Return Line
Paint #2 Trigger
Solvent #1 Supply
Solvent #2 Supply
Turbine Air #1
Turbine Air #2
Natural
Natural
Red
Natural
Orange
Yellow
Natural
Natural
Green
Black
Natural
Silver
Blue
Natural
Natural
Natural
Natural
Natural
Green
Green
LN-9240-02.1
