Ransburg Turbodisk 2 Assembly 78715 - Manual (Page 55)

Turbodisk 2 - Parts Identification
51
1 Fitting, Fluid, Female, 3/8 O.D. Tube, Quick Disconnect 78702-02 1
2 Nut, Hex, 11/16, 3/8 O.D. Tube, SST 70591-03 1
3 Ferrule, Back, Tube, 3/8 70606-03 1
4 Ferrule, Front, Tube, 3/8 70607-03 1
5 Tubing, 3/8 O.D. x 1/4 I.D., (FEP) SSP-5020 7"
6 Fitting, Male Connector, 3/8 O.D. Tube x 1/4 NPT, SST 41-FTC-1002 1
7 Fitting, Street Tee, 1/4 NPT (M) x 1/4 NPT (F), SST LSFI0004-01 1
8 Valve, Check, 1/4 NPT (M) x 1/4 NPT (M) SSV-809 1
9 Fitting, Elbow, 1/4 O.D. Tube x 1/4 NPT (F), SST LSFI0006-01 1
10 Tubing, 1/4 O.D. x .170 I.D., (FEP) 76698-01 8"
11 Nut, Hex, 9/16, 1/4 O.D. Tube, SST 70591-01 1
12 Ferrule, Back, Tube, 1/4 70606-01 1
13 Ferrule, Front, Tube, 1/4 70607-01 1
14 Fitting, Fluid, Female, 1/4 O.D. Tube, Quick Disconnect 78702-01 1
78732 FLUID SUPPLY LINE PACKAGE - PARTS LIST (Figure 18)
LN-9240-02.1
Item # Part # Description Qty
