Ransburg Turbodisk 2 Assembly 78715 - Manual (Page 67)

Turbodisk 2 - Parts Identification
63
1 Bulkhead, Machined, Turbodisk 2 78185-00 1
2 Flange, Machined, Turbodisk 2 Support 70147-00 1
3 Flange, Machined, Nylon Support 70148-00 1
4 Screw, 1/4-20 x 3/4 Long, Nylon Hex Head 4322-24C 6
5 Screw, 5/16-24 x 1" Long, Hex Head 8156-32F 2
6 Lock Washer, 5/16 Helical Spring 7734-07 2
7 Screw, 1/4-20 x 1/2" Long, Hex Head 7958-16C 6
8 Lock Washer, 1/4 Internal Tooth 7776-06 6
9 Flat Washer, 1/4 Nylon 72471-01 4
10 Nut, 1/4-20 Nylon Hex 72472-09 4
11 Boot, Strain Relief 72128-00 1
12 Plug, Machined, Feed Tube Adjustment 70909-00 2
13 Shroud, Machined 78186-00 1
14 Latch, Machined, Shroud 78184-00 4
15 Screw, #6-32 x 1/2 Long, Nylon Flat Heat 78188-00 16
16 Nut, #6-32 Nylon, Hex 8351-08 16
17 Kit, Turbodisk 2 Shroud Disposable Cover (Not Shown) 78143-00 1
78189 TURBODISK 2 QUICK RELEASE FAIRING ASSEMBLY - PARTS LIST (Figure 24)
LN-9240-02.1
Item # Part # Description Qty
