SETUP PROCEDURE
1. Insure that ground connections, cart ground,
and applicator ground are made to a true earth
ground.
INSTALLATION
2. Provide air filtration to the manifold that has the
capability of passing 136 SCFM with particu-
late removal of .3 to .6 micron particle size.
(Bearing air filtration is provided with the stand.)
3. Provide a minimum 1/2-inch I.D. air line to the
filter at the manifold inlet. A minimum of 100
psig pressure is required at the manifold inlet.
4. Install water supply line and air pressure line
to the pressure pot.
W A R N I N G
!
> NEVER use solvent as a test fluid for this
device!
> Using any material OTHER than distilled
water or de-ionized water may cause fire
during the test. Use only distilled or deionized
water to test the applicator.
W A R N I N G
!
> If true earth ground is not made, injury to
personnel or serious damage may occur to
the equipment .
> Insure ALL items in the test area are ground-
ed. Insure there are NO open containers of
flammable materials in the test area.
INITIAL TEST SETTINGS
1. Set RMA-202 type switch to dual or single
fluid depending upon applicator. (See Figure
8)
2. HV is off unless instructed to turn on. Main
power off.
3. Fluid enable off (toggle switch lever in the down
position).
4. Supply 100 psig air pressure to the stand, ref-
erence supply air gage on panel. If required,
adjust air input regulator attached to stand.
5. All toggle switches in the off position (lever in
down position).
6. Attach the applicator to the manifold plate us-
ing the proper spanner wrench. Tighten as re-
quired. (Note: Lubricate o-rings prior to as-
sembly.)
7. Set speed select to 00.
8. Adjust bearing air regulator to 80 psig mini-
mum.
HIGH VOLTAGE TEST
The purpose of the high voltage test is to insure
all voltage-generating components are set or
installed properly. If the applicator is not properly
rebuilt, a voltage deficiency will be identified while
the applicator is off-line and no downtime should
occur.
5. Plug the unit into a suitable 110/120V outlet.
N O T E
> Using tap water or city water MAY CAUSE
problems with chemical incompatibilities with
the production spray material.
RMA-202 Test Stand - Installation
