INSTALLATION
15
Evolver Solventborne Robotic Atomizers - Installation
EVOLVER ROBOTIC
ATOMIZER INSTALLATION
This information is intended ONLY to indicate the
general installation parameters of this product and,
where applicable, its working relationship to other
Ransburg system components in typical use. Each
installation is unique and should be directed by an
authorized Ransburg representative or conducted
from the Ransburg installation drawings provided
for your particular installation.
POWER SUPPLY
ASSEMBLY
Refer to the most current Power Supply Unit
manuals for complete information regarding power
supply installation.
>
The power supply MUST be located outside the
HAZARDOUS area (Reference OSHA, NFPA-33, and
your insurance company requirements.)
>
User should be aware of, and adhere to, all
local fire codes and ordinances.
>
The user MUST provide a properly fused discon-
nect between the power source and the power
supply which complies with appropriate codes.
>
Fluid supply must be grounded per NFPA-33.
W A R N I N G
!
AA-03-02.11
