Ransburg 9040 Classic HV Power Supply 77070-33 - Manual (Page 13)

CP-08-01
9040 Classic HV Power Supply - Installation
1 0 1 0 1 0 1 0 1 0
INPUT CONNECTIONS INPUT CONNECTIONS INPUT CONNECTIONS INPUT CONNECTIONS INPUT CONNECTIONS
Plug the AC line cord into a properly grounded
AC outlet.
EXTERNAL EXTERNAL EXTERNAL EXTERNAL EXTERNAL
CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS
High V High V High V High V High Voltage (High V oltage (High V oltage (High V oltage (High V oltage (High Voltage) oltage) oltage) oltage) oltage)
Cable Connection Cable Connection Cable Connection Cable Connection Cable Connection
Remove the plastic protective plug from the high
voltage cable connector and apply enough LSCH-
0009 dielectric lubricant onto the high voltage
cable to cover the electrical contact point.
Safety Ground Safety Ground Safety Ground Safety Ground Safety Ground
Crimp the appropriate connector onto the ground
wire assembly and install from the power supply
ground stud, located on the side panel, to a true
earth ground.
Interlocks Interlocks Interlocks Interlocks Interlocks
The AC power line must be series interlocked with
both the exhaust fan and conveyor. To interlock
the 9040 Classic High Voltage Power Supply with
the exhaust fan and conveyor, perform the
following:
1. Ensure the front panel fuse is removed, the
power supply is unplugged, and the ON/OFF
switch is in the OFF position.
2. Open the power supply cabinet door.
> In general, conduit must be used for ap-
proved AC installation, however, if national
and local codes permit, the AC power may
be supplied via the factory installed line
cord. If conduit is utilized, the power supply
wiring MAY be routed through an optional
explosion proof switch mounted on or near
the spray booth where it will be convenient
to the operator.
N O T E N O T E N O T E N O T E N O T E
> When connecting external wires to the
9040 Classic High Voltage Power Supply,
route the wiring through the external wir-
ing grommet located on the side panel.
N O T E N O T E N O T E N O T E N O T E
> Applying LSCH-0009 dielectric lubri-
cant on the high voltage cable contact sig-
nificantly reduces corona discharge that
can cause deterioration of the high volt-
age connection components.
N O T E N O T E N O T E N O T E N O T E
> ALWAYS ALWAYS ALWAYS ALWAYS ALWAYS ensure that high voltage is
OFF OFF OFF OFF OFF before flushing the spray gun with
solvent. NEVER
NEVER NEVER NEVER NEVER flush the spray applicator
with high voltage ON ON ON ON ON, as this is a severe fire
hazard and risk to personnel safety. It is
recommended that the high voltage control
be interlocked with the solvent flush signal
so that high voltage is automatically locked
out whenever flushing occurs. Consult your
authorized ITW Ransburg representative for
information on interlocking the high voltage
OFF
OFF OFF OFF OFF signal with the solvent flush signal.
W A R N I N G W A R N I N G W A R N I N G W A R N I N G W A R N I N G !!!!!
> ALWAYS ALWAYS ALWAYS ALWAYS ALWAYS double check that the power
supply is unplugged from its AC outlet
before working with any internal wiring.
W A R N I N G W A R N I N G W A R N I N G W A R N I N G W A R N I N G
!!!!!
> The ground wire assembly MUST MUST MUST MUST MUST be
connected from the power supply ground
stud to a true earth ground.
W A R N I N G W A R N I N G W A R N I N G W A R N I N G W A R N I N G
!!!!!
ARCHIVE
