CP-08-01
INST INST INST INST INSTALLA ALLA ALLA ALLA ALLATION TION TION TION TION
LOCA LOCA LOCA LOCA LOCATION TION TION TION TION
Install the 9040 Classic High Voltage Power
Supply in an area outside the hazardous location,
where it will be protected from the possibility of
environmental intrusion, such as dust or moisture,
and ambient temperatures do not exceed 120
o F
(49 °C), but as close to the applicator as possible
to minimize the length of high voltage cable.
INPUT INPUT INPUT INPUT INPUT VOL VOL VOL VOL VOLT T T T TAGE AGE AGE AGE AGE
SELECTION SELECTION SELECTION SELECTION SELECTION
The 9040 Classic High Voltage Power Supply
accepts universal input voltage between 90 and
264 VAC. There is no need to change any switch
settings when changing input from 115 to 230 VAC
or from 230 to 115 VAC.
> The 9040 Classic High Voltage Power
Supply MUST MUST MUST MUST MUST be located outside the
hazardous area. (See local or national
installation codes and ITW Ransburg
Bulletin - "Operating Your Electrostatic
Coating System Safely").
> The user MUST MUST MUST MUST MUST read and be familiar
with the "SAFETY" section of this manual.
> This manual MUST MUST MUST MUST MUST be read and thor-
oughly understood by ALL ALL ALL ALL ALL personnel who
operate, clean, or maintain this equipment!
Special care should be taken to ensure that
the warnings and requirements for operat-
ing and servicing safely are followed. The
user should be aware of and adhere to ALL
ALL ALL ALL ALL
local building and fire codes and ordinances
as well as any local country codes prior to
installing, operating, and/or servicing this
equipment.
W A R N I N G W A R N I N G W A R N I N G W A R N I N G W A R N I N G
!!!!!
> As each installation is unique, this infor-
mation is intended to provide general instal-
lation information for the 9040 Classic High
Voltage Power Supply. Consult your autho-
rized ITW Ransburg distributor for specific
directions pertaining to the installation of
your equipment.
N O T E N O T E N O T E N O T E N O T E
> 9040 units shipped from the factory for
230 VAC input will have a 72771-01, 0.5
amp front panel fuse installed. If the other
input is required, it is recommended that the
fuse be changed in order to keep the same
level of protection. Both fuses are shipped
with 9040 High Voltage Power Supplies.
N O T E N O T E N O T E N O T E N O T E
> DO NOT DO NOT DO NOT DO NOT DO NOT locate the power supply
near or adjacent to heat producing equip-
ment such as ovens, high wattage lamps,
etc.
C A U T I O N C A U T I O N C A U T I O N C A U T I O N C A U T I O N !!!!!
9040 Classic HV Power Supply - Installation
9 9 9 9 9
