Ransburg AquaTank - Manual (Page 9)

IS-99-01.4
AquaTank - Introduction
6
SPECIFICATIONS
Pneumatic
5 Gallon/30 Liters
Agitator Assy. No.: 76103-05
Air Requirements: 15 psig over tank
pressure (1 bar)
2 Gallon/10 Liters
Agitator Assy. No.: 76103-02
Air Requirements: 15 psig over tank
pressure (1 bar)
Maximum Agitator
Inlet Pressure: 100 psig (1 bar)
5 Gallon/30 Liter Tank
Part No.: LAQU5030-00
Height: 32" (81.3 cm)
Diameter: 21" (53.3 cm)
Capacity: 5 gallons (30 liters)
Weight: 108 lbs. (45 kg)
Pressure Rating: 55 psi (3.74 bar)
2 Gallon/10 Liter Tank
Part No.: LAQU5010-00
Height: 25" (53.3 cm)
Diameter: 15" (38.1 cm)
Capacity: 2 gallons (10 liters)
Weight: 60 lbs. (27.2 kg)
Pressure Rating: 80 psi (5.44 bar)
MATERIALS OF
CONSTRUCTION
All wetted fluid parts are constructed of Delrin,
fiberglass, or stainless steel, HD Polyethylene.
> DO NOT use or store the AquaTank in
temperatures below 40 o F (5 o C) or above
110 o F (45 o C).
W A R N I N G
!
