IS-99-01.4
AquaTank - Installation
8
6. If initial installation, remove fluid outlet cover
bolts (Item 1). Insert approved Ransburg
waterborne hose through the strain relief.
AGITATOR
INSTALLATION
(Refer to Figure 4)
1. Remove ALL pressure from the AquaTank.
7. Connect the hose (3/8" ODT) into the fitting
and tighten securely.
8. Replace fluid outlet cover and secure bolts
(Item 1).
9. Secure strain relief bolts.
2. Remove the star-grip nuts which secure the
tank lid to the tank.
3. Remove the bung lid adapter and store for use
at a later time.
4. Remove the screw (Item 46) and mixer (Item
45) from the assembly.
5. Place the entire unit through the bung hole and
tighten into place.
6. Reinstall screw (Item 46) and mixer (Item 45)
into unit.
7. Reinstall lid and tighten the star-grip nuts.
8. Attach a 1/4" ODT regulated air line to bulkhead
fitting (Item 31).
9. Turn the air pressure up to 15-20 psig above
tank pressure. This cycles the AquaTank at
the proper rate.
> Without filter/separator, dirt or
other contaminants may enter your
material and destroy the finish of a
NOTE
> Ensure that the ground sheath of the
waterborne hose has been stripped back at
least 6" to 12" from the outlet fitting (Item 26).
C A U T I O N
!
> Grounded or static dissipating air
hoses MUST NOT be used to supply
air to the tank.
NOTE
> Pressure Relief Procedure: High pressure
can cause serious injury. Pressure is main-
tained in a pressure tank after the system
has been shut down. Before attempting
removal of fill plug or cover, pressure must
be relieved using the following steps:
• Ensure the power supply is turned OFF.
• Turn OFF the main air supply to the tank.
• BLEED OFF air in tank by pulling the air
relief valve stem, or use a relief valve at
the regulator. Wait until all the air has es-
caped through the valve before removing
the pressure tank cover or fill plug.
W A R N I N G
!
