DR-1 Plastic Fluid Regulator - Parts Identification
16
* Parts contained in Repair Kit
** Recommended Spare Parts
*** Complete Regulator Part Number is 75902-XXA for Aerobell 33A (Fixed Mount) or
75902-XXB for Aerobell 33R (Robot Mount)
Item #
DR-1 PLASTIC FLUID REGULATOR - PARTS LIST (Figures 1 & 3)
Part # Description Qty
Select Options Below DR-1 Regulator Assembly***
75902-01 Ratio 1:1
75902-02 Ratio 1:2
75902-03 Ratio 1:3
75902-04 Ratio 1:4
75902-06 Ratio 1:6
75902-08 Ratio 1:8
75902-10 Ratio 1:10
1 75881 Cap 1
Select Options Below Spacer Ring, For:
2 75880-01 Ratio 1:1 1
75880-02 Ratio 1:2 1
75880-03 Ratio 1:3 1
75880-04 Ratio 1:4 1
75880-06 Ratio 1:6 1
75880-08 Ratio 1:8 1
75880-10 Ratio 1:10 1
3 75879 Lower Housing 1
4** LSFA0015-00 Screw, Slotted 8
Select Options Below Upper Diaphragm Retainer, For:
5 74155-00 Ratio 1:1 1
75374-01 Ratio 1:2 1
75374-06 Ratio 1:3 1
75374-02 Ratio 1:4 1
75374-03 Ratio 1:6 1
74155-00 Ratio 1:8 1
74155-01 Ratio 1:10 1
6** 74156-00 Diaphragm Retainer, Lower 1
7 74231-00 Diaphragm Retainer, Center 1
8* 74273-00 Diaphragm, Lower 1
9* 74157-03 Diaphragm, Upper 1
10* SSG-8172 O-Ring 3
11** 74160-00 Needle and Seat, Regulating 1
12** 74161-00 Spring 1
13 75920 Retaining Plug, Aerobell 33R (Robot Mount) 1
14* 74157-04 Diaphragm, Center 1
15* 74183-20C Screw, Pan Head 1
16 LREG0002 Bleed Spacer 1
17 LSFI0041-01 Elbow, 1/4" OD Tube x 1/8" NPT,
Special Regulator Outlet 1
19** 75950-01 10-32 Right Angle Barb Fitting 2
20** 73913-01 Repair Kit
LN-9228-00.3
