9060 High Voltage Controller - Installation
CP-13-05.2
28
N O T E S
8. Complete the control system I/O wiring be-
fore reconnecting the 9060 Controller to
the AC source.
9. Secure the cabinet door, replace the fuses,
and reconnect the AC source.
10. Refer to the “Operations” section of this
service manual and use the “Remote I/O
monitoring diagnostic mode” to verify that
all of the I/O input connections are func-
tioning.
