9060 for No. 2 Process Handgun - Installation
13 CP-13-03.2
GENERAL INFORMATION
The following section contains general infor-
mation on the installation of 9060 High Voltage
Controller.
INSTALLATION
The 9060 Controller MUST be located a
minimum of 6.1m (20’) outside or away
from the target being sprayed.
The User MUST read and be familiar
with the “Safety” section of this manual.
This manual MUST be read and thor-
oughly understood by ALL personnel who
operate, clean, or maintain this equipment!
Special care should be taken to ensure that
the warnings and requirements of operating
and servicing safely are followed. The user
should be aware of and adhere to ALL local
building and fire codes and ordinances as
well as NFPA-33, OSHA, and all related
country safety codes prior to installing, op-
erating, and/or servicing this equipment.
Only approved applicators should be
used with the 9060 High Voltage Controller.
! W A R N I N G
DO NOT locate the Controller near or
adjacent to heat producing equipment
such as ovens, high wattage lamps, etc.
! C A U T I O N
As each installation is unique, this infor-
mation is intended to provide general in-
stallation information for the 9060 Control-
ler. Consult your authorized Ransburg
distributor for specific directions pertaining
to the installation of your equipment.
N O T E
LOCATION OF THE 9060
Install the Controller in an area must be 6.1m
(20’) from where the spray target is located
in accordance with federal, state, and local
codes. The area should protect the Controller
from the possibility of environmental intrusion
(such as dust or moisture), have ambient
temperatures that do not exceed 40°C, and be
as close to the applicator as possible to mini-
mize the length of the high voltage cable.
AC INPUT CONNECTIONS
For non-conduit installations, plug the detacha-
ble AC line cord into the receptacle on the side
of the 9060 Controller. Plug the other end of
the line cord into a properly grounded 120 volt
AC outlet.
For those few installations where it is required
to run the AC input wiring in conduit, perform
the following:
1. Ensure the AC line cord is unplugged
and remove the AC inlet receptacle wiring
from TB1-N, TB1-L1 and TB1-EARTH
GROUND (See Figures 5).
2. Remove the mounting hardware from the
AC inlet receptacle and remove it from the
side of Controller.
3. Install the Conduit Adapter Plate (supplied)
in the hole where the AC inlet receptacle
was removed (see Figure 6).
4. Install the AC input wiring (0.8mm
2
