neVer put hands or Face dIrectly oVer burner whIle lIghtIng.
Figure 1
multipurpose lighter paperbook match
Figure 2
Figure 3 Figure 4 Figure 5
lIghtIng and operatIng InstructIons
the cooKer must not be lIt untIl the precedIng
placement InstructIons haVe been completely Followed.
1. Check the burner to make sure it is set up as per the illustration (Figure 1). when smoking, the smoker
cabinet must be in place before lighting. when using this appliance as a smoker, never light the
burner with the smoker doors closed. never lean into the smoker chamber while lighting. the rear
access door located on the back of the smoker must be opened while lighting. note: when
opening rear access door, move gas cylinder to side of smoker (hinge side) in order to open door
fully. when the door is closed return the cylinder to the position as listed in Figure 2, pg. 15.
2. Place the end of a lit multipurpose lighter above the burner as per Figure 3, or use a lit paper book
match placed above the burner as per Figure 4. Turn the manual valve control toward the “ON” position
(Figure 2) until ignition occurs. Turning the manual valve counterclockwise increases the gas flow to the
burner and hence the flame size (Figure 5).
When lighting the burner, if ignition does not occur in 3 to 5 seconds, turn the manual valve clockwise
until it stops. This is the OFF position. Wait 5 minutes for gas to disperse. Repeat lighting procedure.
3. Check that the flame is blue and that the flames are emitted completely around the burner (see Figure
5). If there is a yellow flame, or if some ports have no flame, this indicates there may be an obstruction
in the venturi tube or ports. Check the maintenance instructions on page 19 for more information
regarding a yellow flame or blockage.
4. Always monitor the flame throughout the cooking process. If at any point in the cooking process the
flame is accidentally extinguished, immediately turn the manual valve OFF. Open smoker doors slowly
(if applicable), wait 5 minutes for gas to disperse and relight the cooker according to the lighting
instructions (#1 - #3) in this section.
* cooker base pictured with
windguard shield Installed.
smoker not pictured.
If using as a smoker make
sure the cabinet is placed over
cooker base without the
windguard shield installed. see
the placement Instructions
located on page 15. when
smoking, the smoker cabinet
must be in place before lighting.
Follow all lighting instructions
above.
