QE Series Joulemeter Instruction Manual Version 3.0 April 2014 13
Footnotes
Model
QE95LP-S-MB
QE95LP-H-MB
QE95ELP-S-MB
QE95ELP-H-MB
Optical Absorber MB
Spectral Range 1, 7 0.19 – 20 µm
Calibrated Spectral Range
(Optional)
(QE-QED Series)
1, 7
0.248 – 2.5 µm
10.6 µm
0.3 – 2.1 µm
Typical Sensitivity 2, 6 2 V/J 0.6 V/J
Calibration Uncertainty 6, 2, 7, 8, 10 ± 3%
Repeatability < 0.5 %
Max. Pulse Energy 1.064 µm
0.266 µm
With QED @ 1.064 µm
QED @ 0.266 µm
3, 11
35 J
30 J
150 J
50 J
70 J
(µs pulse, single shot)
250 J
(µs pulse, single shot)
Noise Equivalent Energy (NEE)
(Typ)
2, 10 15 µJ 30 µJ
Max. Repetition
Rate
2, 4, 10 40 Hz 10 Hz
Typical Rise Time
(0-100%)
2, 10 2000 µsec 6000 µsec
Max. Pulse Width (Typ) 2, 5, 9, 10 1500 µsec 5000 µsec
Max. Energy Density
11
1200 mJ/cm
2
@ 1064nm, 150µs, 10 Hz
600 mJ/cm
2
@ 1064nm, 7ns, 10 Hz
500 mJ/cm
2
@ 266nm, 7ns, 10 Hz
Max. Energy Density with QED
14 J/cm
2
@1064nm, 150µs, 10Hz
16 J/cm
2
@1064nm, 7ns, Single shot
8 J/cm
2
@1064nm, 7ns, 10Hz
6 J/cm
2
@532nm, 7ns, 10Hz
1 J/cm
2
@266nm, 7ns, 10Hz
Max. Average Power
Detector Alone (QE95xP-S-MB):
With optional Heatsink (QE95xP-H-MB):
11, 12
20 W (45 W with QED)
40 W (90 W with QED)
Max. Power Density
Detector Alone (QE95xP-S-MB):
With optional Heatsink (QE95xP-H-MB):
With QED :
10 W/cm² @ 12 W
5 W/cm² @ 40 W
600 W/cm²
Dimensions (H x W x D)
Detector Alone (QE95xP-S-MB):
With optional Heatsink (QE95xP-H-MB):
122 x 122 x 20 mm
122 x 122 x 98 mm
Weight
Detector Alone (QE95xP-S-MB):
With optional Heatsink (QE95xP-H-MB):
780 g
1200 g
Aperture Size
QE 95:
QED 95:
95 mm in diameter
90 mm in diameter
Aperture Area Size
QE 95:
QED 95:
71 cm
2
64 cm
2
