Revision 1.5 5
FLASH Series Instruction Manual Gentec Electro-Optics Inc. All rights reserved
1.4.1 Power mode
Specifications are subject to change without notice.
1 Over 10KW the numerical resolution is 0.1KW
2 The FLASH-500-10S/20R5-IPL and the FLASH-500-55-W-IPL have the same specifications that the FLASH-500-55 except for the
measurement accuracy and wavelength range. For these instruments typical power sensitivity is used.
1.4.2 Energy mode
See power mode specifications for operating and storage temperature ranges.
Parameter
2
FLASH-500-55 FLASH-3K-55 FLASH-6K-55 FLASH-10K-55
Spectral range 0.19-20 µm
Power Range 0.1 - 500 W 5 - 3000 W 20 – 6000 W 30 – 10 000 W
Maximum Average Power Density-
1064nm CW
At 100 W average power
At 500 W average power
At 3000 W average power
At 6000 W average power
At 10000 W average power
25 KW/cm
2
5.0 KW/cm 2 7.0 KW/cm 2
5.0 KW/cm
2
8.0 KW/cm
2
7.0 KW/cm
2
7.0 KW/cm
2
5.5 KW/cm
2
Display Numerical Resolution 0.1W 1W 1W 1W
1
Measurement Accuracy

3%

5%

5%

5%
Noise Equivalent Power (NEP) 0.1W 5W 20W 30W
Maximum Allowable Absorber Temp. 65°C 65°C 75°C 75°C
Battery 2 x AA
Battery Life 5000 measurements
Operating Temperature range 10 to 40 °C < 80% Relative humidity
Storage Temperature range 10 to 60 °C < 90% Relative humidity
Response time 5 s 10 s 5 s 5 s
Maximum Laser Beam Diameter Ø 55 mm
Maximum number of readings before
probe must be cooled
[for 25°C starting temp.]
100W 25
200W 12
300W 8
500W 5
0.5KW 6
1KW 3
1.5KW 2
3KW 1
1KW 6
2KW 3
3KW 2
6KW 1
1KW 10
2KW 5
5KW 2
10KW 1
Maximum esposure time before probe
must be cooled to 25°C
[for 25°C starting temp.]
(This is the total time for all the readings)
100W 200s
200W 100s
300W 60s
500W 40s
0.5KW 72s
1KW 36s
1.5KW 24s
3KW 12s
1KW 36s
2KW 18s
3KW 12s
6KW 6s
1KW 60s
2KW 30s
5KW 12s
10KW 6s
Weight [g] 930 1240 1520 2150
Dimensions [mm] 88X35X335 88X45X335 88X36X335 88X46X335
