Revision 1.5 6
FLASH Series Instruction Manual Gentec Electro-Optics Inc. All rights reserved
Parameter FLASH-500-10S/20R5-IPL 1 FLASH-500-55-W-IPL
Spectral range µm 0.19-20 0.19-2.5
-Optical aperture
cm
2
1 23.76
mm
10S : 10X10mm
20R5 : 20X5mm
Ø 55mm
Typical sensitivity mV/J 0.013
Typical Power sensitivity /
Typical Energy sensitivity
J/W 5
Response Time s 2
Minimum repetition period s 15
Maximum pulse width ms 433
Energy range
(For 1.064µm ; 10ms pulse)
J 2 - 350
Maximum Average Power
Density-1064nm CW @ 10W
KW/cm
2
45
Pulsed Laser Damage
Thresholds (10ms)
J/cm
2
175
Noise equivalent energy mJ 500
Accuracy % ± 5
1
The FLASH-500-55 has the same specifications that the FLASH-500-55-W-IPL except for the accuracy and
wavelength range.
For the Flash-500-55, FLASH-3K-55, FLASH-6K-55 and FLASH-10K-55 typical energy sensitivity is used.
Energy calibration is available on special request for any Flash model.
2 OPERATING INSTRUCTIONS
Laser power detection is completely automatic. There is no need for an external timer.
