SPECIFICATIONS
Handle Display Type Thin-film transistor (TFT) liquid crystal
Size 2.4 in. (61mm) diagonal
Resolution 320 x 240 pixels
Estimated battery life 8 hours
Operating temperature 32° to 140°F (0° to 60°C)
Storage temperature 32° to 140°F (0° to 60°C)
Dimensions 3.68 x 8.25 x 2.26 in. (93.5 x 209.5 x 57.5mm)
Weight (w/battery) 12.6 oz. (357g)
Power source 4 “AA” batteries
Probe Diameter 4.9mm (0.19 in.)
Length 1m (39.37 in.)
Operating temperature 32° to 131°F (0° to 55°C)
Water resistance To IP57 standards
Head material Stainless steel
Head length 36mm (1.42 in.)
Depth of field Horizontal field angle: 45.2°
Vertical field angle: 34°
Diagonal field angle: 56°
Light source 3 LEDs, each w/luminous intensity of
140 to 224 mcd (millicandelas)
Weight 5.1 oz. (145g)
