SPECIFICATIONS

Transmitter

Output Signal Frequency

125 kHz

Voltage Measurement Range/Accuracy

12 to 600V AC or DC /±2.5%

Display

2.4 in. (61mm) diagonal LCD

Dielectric Strength

400V AC/DC, max

Overvoltage Rating

CAT III 300V

Power Consumption

31mA (min), 115mA (max)

Fuse Rating/Dimensions

500mA @ 1000V/6.3mm (diameter)
x 32mm (long)

Operating Temperature

32° to 104°F (0° to 40°C) @ <80% RH

Storage Temperature

-4° to 140°F (-20° to 60°C) @ <80% RH

Dimensions

7.5 x 3.5 x 1.7 in. (190 x 89 x 43mm)

Weight

12.7 oz. (360g) without battery;
14.8 oz. (420g) with battery

Power Source

One “9V” battery

Receiver

Line Voltage Detection Range

~1.3 ft. (0.4m)

Cable & Pipe

Single-pole Applications

~6.6 ft. (2m)

Location Range

Two-pole Applications

~ 2 ft. (0.5m)

Display

2.4 in. (61mm) diagonal LCD with backlight

Auto Power Off Trigger

10 minutes of inactivity

Operating Temperature

32° to 104°F (0° to 40°C) @ <80% RH

Storage Temperature

-4° to 140°F (-20° to 60°C) @ <80% RH

Power Consumption

32mA (min), 89mA (max)

Dimensions

9.5 x 3.1 x 1.5 in. (242 x 78 x 39 mm)

Weight

9.9 oz. (280g) without battery;
12.3 oz. (350g) with battery

Power Source

Six “AAA” batteries
