FTZÚ, Pikartská 7, 716 07 Ostrava Radvanice, tel +420 596 232 715, fax +420 596 232 672, e-mail: [email protected]

-Physical Technical Testing Institute

Ostrava-Radvanice

(1)

EC-Type Examination Certificate

(2)

Equipment or Protective Systems Intended for use

in Potentially Explosive Atmospheres

Directive 94/9/EC

(3) EC-Type Examination Certificate Number:

FTZÚ 04 ATEX 0293X

(4) Equipment or protective system: Drum pumps of type PFS ..

(5) Manufacturer : FINISH THOMPSON INC.

(6) Address: 921 Greengarden Road, Erie, PA 16501-1591, USA

(7) This equipment or protective system and any of acceptable variation thereto is specified in the

schedule to this certificate and the documents therein referred to.

(8) The Physical Technical Testing Institute, notified body number 1026 in accordance with Article 9

of the Council Directive 94/9/EC of 23 March 1994, certifies that this equipment or protective
system has been found to comply with the Essential Health and Safety Requirements relating to
the design and construction of equipment and protective systems intended for use in potentially
explosive atmospheres given in Annex II to the Directive.

The examination and test results are recorded in confidential Report N

04/0293 dated 8 September 2004

(9) Compliance with Essential Health and safety requirements has been assured by compliance with:

EN 1127-1:1997

EN 13463-1:2001

EN 13463-5:2003

(10) If the sign „X“ is placed after the certificate number, it indicates that the equipment or protective

system is subject to special conditions for safe use specified in the schedule to this certificate.

(11) This EC-TYPE EXAMINATION CERTIFICATE relates only to the design, examination and testing

of the specified equipment or protective system in accordance to the directive 94/9/EC.
Further requirements of the Directive apply to the manufacturing process and supply of this
equipment or protective system. These are not covered by this certificate.

(12) The marking of the equipment or protective system shall include following:

II 1/2G c II C T5

.. T4

This EC-Type Examination Certificate is valid till:

Responsible person:

Date of issue:11.09.2004

Dipl. Ing. Šindler Jaroslav

Number of pages: 2

Head of certification body

This certificate is granted subject to the general conditions of the Physical Technical Testing Institute.

This certificate may only be reproduced in its entirety and without any change, schedule included.

Physical Technical Testing Institute

FTZÚ, Pikartská 7, 716 07 Ostrava Radvanice, tel +420 596 232 715, fax +420 596 232 672, e-mail: [email protected]

Ostrava-Radvanice

(13)

Schedule

(14)

EC-Type Examination Certificate N° FTZÚ 04 ATEX 0293X

(15) Description of Equipment or Protective System:

A type PFS drum pump is used for transferring fluids from one container to another. There are five

different lengths available for the PFS pump and they are as follows : 68, 101, 122, 152 a 183

cm. Each pump has the same construction materials and design. The pump consists of a carbon

fiber filled impeller housed in a stainless steel impeller housing. A stainless steel shaft , is running

through the pump tube and is supported by two bushings, drives the impeller. PFS pump can

handle fluids up to 104°C ( 220 °F), and 330 cP. The pump is equipped by a static protection kit

to connect the pump to earth ground.

The pump may be equipped by following types of air motors:

Pneumatic drive

M6 M6X

300-6000 rpm

300-3000 rpm

0,37 kW

0,56 kW

II 2G c T5

(16) Report No. : 04/0293

(17) Special conditions for safe use:

Fluid temperature

Temperature class

for ambient

temperature 40°C

up to 24 °C

up to 104 °C

(18) Essential Health and Safety Requirements:

Covered by standard mentioned in (9) of this certificate.
