Fairbanks MATRIX SCALE HIGHWAY SCALE SYSTEM User Manual
Page 28
Section 4: Wiring
11/12
28
51182 Rev. 2
Dip (Address) Switch Setup, SSCs continued
• Switches
6 thru 10
set the Section [Address] Numbers.
• Set the Section Number according to the following chart.
• Each SSC Box has a unique Section Number entered on the dip switches.
Section Number
6
7
8
9
10
Section 1
On
Off
Off
Off
Off
Section 2
Off
On
Off
Off
Off
Section 3
On
On
Off
Off
Off
Section 4
Off
Off
On
Off
Off
Section 5
On
Off
On
Off
Off
Section 6
Off
On
On
Off
Off
Section 7
On
On
On
Off
Off
Section 8
Off
Off
Off
On
Off
Section 9
On
Off
Off
On
Off
Section 10
Off
On
Off
On
Off
Section 11
On
On
Off
On
Off
Section 12
Off
Off
On
On
Off
Section 13
On
Off
On
On
Off
Section 14
Off
On
On
On
Off
Section 15
On
On
On
On
Off
Section 16
Off
Off
Off
Off
On
Switch Settings
