Section 5: Operation
04/12
39
51147 Rev. 3
5.2. VIEWING OPTIONS
When using the
Kernel Program
, there are two viewing options for weighing.
The GTN Screen
The GTN Screen displays the weighments for only .one scale at a time.
Multi-scale Screen
The Multi-scale Screen displays all configured scales on the screen at one time.
─
The Golden Diamond show which weighment is being used
─
The scale being used is identified in the lower-left corner of the screen.
5.3. GROSS WEIGHING
21. Press the
ZERO
key to zero the scale.
22. Place the object to be weighed on the platform.
23. View the weight from the screen.
NOTE:
The Operating Mode is
Service-Programmable only
.
The GTN Screen application
The Multi-Scale Screen application
