Steps in customizing, continued – Fairbanks FB3000 Kernel Program Operators Manual User Manual
Page 22
Section 4: Input/ Output (I/O)
04/12
22
51147 Rev. 3
4.2.7. Steps in Customizing, Continued
Window Name
Description
CONFIGURE OUTPUT,
─
Build Tab
Configures the data string protocol order, written in
ASCII text.
By left-clicking in any item, a drop-down menu offers different
parameters, or removes them.
Text may be added to the data string by clicking in the
Value
field, then
entering it.
─
Also by clicking into the
Data Type
box and choosing text from
the drop down box.
A drop-down Menu Window opens
when any
Data Type
choice is
selected by left-clicking in the field
