49 -

WMM/ QoS

The WMM page shows the Wi-Fi Multi-Media power save function and Direct Link Setup that ensure

the wireless network linking quality.

WMM/QoS Tab

WMM Enable

Check the box to enable Wi-Fi Multi-Media function that is meant to improve
audio, video and voice applications transmitted over Wi-Fi.

WMM- Power Save
Enable

Select a power save mode that preferred.

z

AC_BK (Access Category Background)

z

AC_BE (Access Category Best Effort)

z

AC_VI (Access Category Video)

z

AC_VO (Access Category Voice)

Direct Link Setup
Enable

Check the box to enable Direct Link Setup (DLS). This function will be
enabled under the connection with AP which must support the DLS function.
Direct Link Setup allows direct STA-to-STA frame transfer within a BSS
(B

asic Service Set

). This is designed for consumer use, where STA-to-STA

transfer is more commonly used.

MAC Address

The setting of DLS( Direct Link Setup) indicates as follow :

Fill in the blanks of Direct Link with MAC Address of target STA, and the
STA must conform to two conditions:

z

Connecting with the same AP that supports DLS feature.

z

DLS enabled.

Timeout Value

Timeout Value represents that it disconnect automatically after few seconds.
The value is integer that must be between 0~65535. It represents that it always
connects if the value is zero. (Default value of Timeout Value is 60 seconds.)

Apply

Click this button to apply the settings.

Tear Down

Select a direct link STA, then click "Tear Down" button to disconnect the STA.
