27 -

Export Profile

Export all credentials to Profile.

Delete

Delete an existing credential. And then select the next credential if exist. If
there is an empty credential, the driver will select any non-security AP.

PIN

Registrar: Add the AP’s PIN code into the PIN code column, and press the
device PIN button. It will connect with the AP in two minutes and get IP
address.

Enrollee: Input the device’s PIN code into the PIN code column of AP. Start
AP WPS process and click device PIN button. Then, the device will connect
to AP in two minutes and get IP address.

PBC

Start to add to AP using PBC (Push Button Configuration) method. Click
this button to connect the AP which supported WPS function within two
minutes. Meanwhile, the AP should also click the PBC button
simultaneously.

Note:

After the users click PIN or PBC, please do not rescan within two minutes of the
connection. If users want to stop this setup within the interval, restart PIN/PBC or
click "Disconnect" to stop WPS action.

WPS Associate IE

Send the association request with WPS IE during WPS setup. It is optional
for STA.

WPS Probe IE

Send the probe request with WPS IE during WPS setup. It is optional for
STA.

Auto

Check this box the device will connect the AP automatically.

Progress Bar

Display rate of progress from Start to Connected status.

Status Bar

Display currently WPS Status.

Radio On/Off

Click this Radio On/Off button to turn ON or OFF radio function.

This icon shows radio on, click to turn it off.

This icon shows radio off, click to turn it on.
