5 front panel (operator interface) – Teledyne 3000MA - Paramagnetic oxygen analyzer User Manual
Page 9
1-3
Percent Oxygen Analyzer
Introduction 1
Teledyne Analytical Instruments
Figure 1-1: Model 3000MA Front Panel
1.5
Front Panel (Operator Interface)
The standard 3000MA is housed in a rugged metal case with all con-
trols and displays accessible from the front panel. See Figure 1-1. The front
panel has thirteen buttons for operating the analyzer, a digital meter, an
alphanumeric display, and a window for viewing the sample flowmeter.
Door Latch
Sample System
Flow Indicator
Standby Switch
Function Buttons
Data Entry Buttons
Digital Meter
Alphanumeric
Display
