Multi-Channel Combustible Monitor Installation 3
Teledyne Analytical Instruments
Installation of the analyzer includes:
1. Unpacking the system
2. Mounting the Channel Module and Control Module
3. Making the electrical connections
5. Making the gas connections
6. Testing the installation
3.1 Unpacking the Analyzer
Each TAI Model 1220 Combustible Gas Monitoring System is gener-
ally shipped with the channel modules and control module installed.
Since the system is intended as a safety monitor for detecting the
presence of combustible gases in industrial environments, the system
enclosure is normally installed in a safe area, while the remote sensors are
installed at potentially hazardous areas up to 12 thousand feet distant.
Numerous case options are available, however. One optional configuration
involves a purgeable case for installation in hazardous areas. This type of
case, which is maintained under a positive pressure, is purged with com-
bustible-free air.
