OPERATION
HPN-IOM-2014-0416
SECTION 3
3-18
!
WARNING
Do not operate, or allow others
to operate, service or repair this
equipment unless you (they) fully
understand all applicable sections
of this manual and are qualifi ed to
operate/maintain the equipment.
Non-Fulton product information is for
reference purposes only. No Fulton
document may substitute for full
review of documentation available
from the component manufacturer.
>NormalOperation.
11. Turn the main ON/OFF switch to OFF. The control will now postpurge.
Verify ignition using steps from Setting Main Burner Ignition with the new
gas pressures.
12. Turn the main burner switch to OFF. The control will now post purge.
13. Under Manual Operation > Auto/Manual/Off , change the operation
to Automatic and press Enter and confi rm Automatic is entered in the
current fi eld.
14. Press Escape twice to get back to the main menu.
15. Under Updating >ParamBackup, select LMV51 – AZL. This will store all
of the adjustments that have been made in the LMV base module to the
display. If the base module fails in the future, the display can be used to
download all of the parameters into a new base module.
16. The heater is now ready to run. Adjust your setpoint on the temperature
control to the desired temperature and turn the main ON/OFF switch to
ON for the burner to operate.
 CHANGING SET POINT ON THE AZL
1. Hit Escape to Select Operation than hit Enter and scroll to Heater Set
point, hit Enter to Set point W1 hit Enter and enter new set point with
Select buttons.
2. When accomplished hit Enter than Escape 3 times to Operational Stats
hit Enter to Normal Operation, hit Enter to get to the main screen.
 FOR MANUAL OPERATION
1. Hit Escape and scroll to Manual, hit Enter to Auto / Manual / Off , change
to Manual and hit Escape to Set Load, change to 0 or desired load range
with the select buttons.
2. When in Manual it will allow you to go to any load range to verify
combustion.
3. When done hit Escape and scroll to Operational Stats, hit Enter to
Normal Operation, hit Enter to main screen.
4. To return back to Auto operation repeat step 1 & 2.
5. Please refer to this manual’s addendum for information on specifi c LMV 51
control parameters.
NOTE:

Do NOT leave unit unattended in Manual Operation, in this mode the LMV
51 will ignore its internal Set Point.
Operating Controls
The following specifi cations, data, equipment and operating descriptions apply
