INSTALLATION
HPN-IOM-2014-0416
SECTION 2
2-14
!
WARNING
All information in this manual is for
reference and guidance purposes,
and does not substitute for required
professional training, conduct,
and strict adherence to applicable
jurisdictional/professional codes and
regulations.
Non-Fulton product information is for
reference purposes only. No Fulton
document may substitute for full
review of documentation available
from the component manufacturer.
TABLE 5 - RECOMMENDED LOADS FOR FLEXITALLIC SPIRAL WOUND CLASS 300# GASKETS
SAE GRADE 5 BOLTS OR EQUAL
Nominal Flange
Size (in.)
Number of Bolts
Diameter of Bolts
(in.)
Preferred Torque
Req. Per Bolt (ft-lb)
1/2
4
1/2
45
3/4
4
5/8
90
1
4
5/8
90
1 1/4
4
5/8
90
1 1/2
4
3/4
150
2 8
5/8
90
2 1/2
8
3/4
150
3 8
3/4
150
3 1/2
8
3/4
150
4
8
3/4
150
5
8
3/4
150
6
12
3/4
150
8
12
7/8
240
10
16
1
368
TABLE 6 - RECOMMENDED LOADS FOR JM CLIPPER ELASTOGRAPH 150# GASKETS SAE
GRADE 5 BOLTS OR EQUAL
Nominal Flange
Size (in.)
Number of Bolts
Diameter of Bolts
(in.)
Preferred Torque
Req. Per Bolt (ft-lb)
1/2
4
1/2
30
3/4
4
1/2
30
1
4
1/2
30
1 1/4
4
1/2
30
1 1/2
4
1/2
30
2 4
5/8
60
2 1/2
4
5/8
60
3 4
5/8
60
4
8
5/8
60
5
8
3/4
100
6
8
3/4
100
8
8
3/4
100
10
12
7/8
160
