13
FG: Ground connection.
DC 5V: Connecting to AC adapter.
WAN: Broadband Router provides four RJ45 type WAN port connecting to
broadband transmission equipments such as ADSL or CABLE Modem via
RJ45 cable.
LAN: Broadband Router provides one RJ45 type LAN port connecting to your
network devices such as Hub/Switch via RJ45 cable. Using a HUB/Switch will
allow more PC connecting to Broadband Router.
Default: If Broadband Router occurs any system crash, you may press this
button to reload factory default value or reset back to latest configuration file
2.1.3 LED Indicator
LEDs Indication
Off Disconnected or undetected
Green Linked
Green Flash Data Transmission
WAN1~4
Red Collision
Green Link 100M
Green Flash 100Mbps Data Transmission
Off Disconnected or undetected
Orange Link 10M
LAN
Orange Flash 10M Data Transmission
